63230-300-212 Appendix A—Abbreviated Register Listing
April 2001 Contents
127
© 2001 Schneider Electric All Rights Reserved
This appendix contains information about the registers of the circuit monitor.
CONTENTS ..............................................127
ABOUTREGISTERS .......................................127
HOWPOWERFACTORISSTOREDINTHEREGISTER ..........128
HOWDATEANDTIMEARESTOREDINTHEREGISTER .........129
REGISTERLISTING........................................130
The four tables in this appendix contain an abbreviated listing of circuit
monitor registers:
• Table A–3, beginning on page 130, identifies registers for these values:
— Real-Time Metered Values including 100 ms and 1 second
— Power Quality
— Minimum Real-Time Meter Values
— Maximum Real-Time Meter Values
— Accumulated Energy Values
— Demand Values
— Phase Extremes
— System Configuration
— Current and Voltage Module (
CVM) Configuration
— Metering Configuration
— Communications
• Table A–4 on page 166 lists the register numbers related to the set up of
inputs and outputs.
• Table A–5 on page 173 identifies the alarm position register numbers.
• Table A–6 on page 178 lists the registers used for the individual per-phase
harmonic magnitudes and angles through the 63rd harmonic for all
currents and voltages.
APPENDIX A—ABBREVIATED REGISTER LISTING
CONTENTS
ABOUT REGISTERS
