Chapter 3—Operation 63230-300-212
Viewing Metered Data April 2001
© 2001 Schneider Electric All Rights Reserved
38
3. Select the option you would like to reset and change No to Yes by
pressing the arrow button.
4. Press Enter to move to the next option or press the menu button to reset
the value.
The Meters menu and the Min/Max menu, shown in Figure 3–7, are view-only
menus where you can view metered data in real time.
Figure 3–7: Viewing metered data on the Meters and Min/Max menus
Use the arrow buttons to scroll through the menu options on the Meters
menu. To select a menu option, press the enter button. To select another
option, press the menu button.
From the Meters menu you can view the following information.
• Summary—lets you quickly move through and view the following:
— Summary total of volts, amperes, and kW.
— Amperes and volts for all three phases, neutral and ground, line to line,
line to neutral.
— Power kW, kVAR, and kVA (real, reactive, and apparent power)
3-phase totals.
— Power factor (true and displacement) 3-phase totals.
— Total energy kWh, kVARh, and kVAh 3-phase totals (real, reactive, and
apparent energy).
— Frequency in hertz.
• Power—is available only if the circuit monitor is configured for 4-wire
system; it will not appear for 3-wire systems. If you are using a 4-wire
system, you can view the leading and lagging values for true and
displacement power factor. Also this option lets you view power per-phase
kW, kVAR, and kVA (real, reactive, and apparent power).
• Power Quality—shows the following values per phase:
— THD voltage line to neutral and line to line.
— THD amperes
— K-factor
VIEWING METERED DATA
MAIN MENU
Meters
Min/Max
View Alarms
I/O Display
Resets
Setup
Diagnostics
METERS
Summary
Power
Power Quality
Energy
Power Demand
Current Demand
MIN/MAX
Current
Voltage
Frequency
Power
Power Factor
THD
Viewing Metered Data
from the Meters Menu
