Chapter 3—Operation 63230-300-212
Configuring the Circuit Monitor Using The Setup Menu April 2001
© 2001 Schneider Electric All Rights Reserved
26
The I/O Extender Setup selection menu displays.
5. Select the Configure Modules menu option.
The IOX Setup menu displays according to the IOX previously selected.
In this example the IOX Custom Setup menu displays.
6. Select the position in which the I/O is installed.
The I/O module’s setup menu displays based on the type of module
installed in the selected position.
NOTE: For a description of the I/O options displayed above, refer to
Chapter 5—Input/Output Capabilities
on page 69.
I/O EXTENDER SETUP
Select Modules
Configure Modules
IOX CUSTOM SETUP
Position 1
Position 2
Position 3
Position 4
Position 5
Position 6
Position 7
Position 8
ANALOG OUTPUT SETUP
Lbl: Analog OutC04
Type 4-20mA Output
I/O Point # 38
Reference Reg 100
Lower Limit 400
Upper Limit 2000
ANALOG INPUT SETUP
Lbl: Analog In C02
Type 4-20mA Input
I/O Point # 36
Multiplier 1
Lower Limit 400
Upper Limit 2000
DIGITAL INPUT SETUP
Lbl: Dig In C01
Type 120Vac Input
I/O Point # 35
Mode Normal
DIGITAL OUTPUT SETUP
Lbl: Dig Out C03
Type 120 Vac Output
I/O Point # 37
Mode Normal
Pulse Const ****
Timer (secs) 0
Control External
Associate Alarm
