A password is always required to access the following menus from the
Main Menu:
• Resets (a separate password can be set up for Energy/Demand Reset
and Min/Max Reset)
• Setup
• Read/Write Regs on the Diagnostics Menu
The default password is 0. Therefore, when you receive a new circuit monitor,
the password for the Setup, Diagnostics, and Reset menu is 0. If you choose
to set up passwords, you can set up a different password for each of the four
menus options listed above.
To set up a password, follow these instructions:
1. From the Main Menu, select Setup.
The password prompt displays.
2. Select 0, the default password.
The Setup menu displays.
3. Select Passwords.
The Password Setup menu displays. Table 3–7 describes the options.
Table 3–7: Options for Password Setup
Option Available Values Description
Setup 0–9998
EnterapasswordintheSetupfieldtocreate
a password for the Setup option on the Main
Menu.
Diagnostics 0–9998
Enter a password in the Diagnostics field to
create a password for the Diagnostics option
on the Main Menu.
Setting Up Passwords
MAIN MENU
Meters
Min/Max
View Alarms
I/O Display
Resets
Setup
Diagnostics
METERS
Summary
Power
Power Quality
Energy
Power Demand
Amp Demand
Custom
VIEW ALARMS
Active Alarms
High Priority Alarms
I/O DISPLAY
Digital Inputs
Analog Inputs
Digital Outputs
Analog Outputs
RESETS
Energy
Demand
Min/Max
SETUP
Display
Communications
Meter
Alarm
I/O
Passwords
DIAGNOSTICS
Meter Information
CVM Information
Read/Write Regs
Wiring Error Test
MIN/MAX
Amps
Volts
Frequency
Power
Power Factor
THD
Figure 3–5: Menus that can be
password protected
Passwords can be set
up for Resets, Setup,
and Diagnostics menus
SETUP
Date & Time
Display
Communications
Meter
Alarm
I/O
Passwords
PASSWORDS
Setup 0
Diagnostics 0
Engy/Dmd Reset 0
Min/Max Reset 0
