Appendix A—Abbreviated Register Listing 63230-300-212
Register Listing April 2001
© 2001 Schneider Electric All Rights Reserved
150
2013 Maximum Demand Voltage A-B D Volts/Scale 0 to 32,767
2014 to 2017 Maximum Demand Date/Time Voltage A-B — See Template See Template
2018 Minimum Demand Voltage A-B D Volts/Scale 0 to 32,767
2019 to 2022 Minimum Demand Date/Time Voltage A-B — See Template See Template
2025 Last Demand Voltage B-C D Volts/Scale 0 to 32,767
2026 Present Demand Voltage B-C D Volts/Scale 0 to 32,767
2027 Running Average Demand Voltage B-C D Volts/Scale 0 to 32,767
2028 Maximum Demand Voltage B-C D Volts/Scale 0 to 32,767
2029 to 2032 Maximum Demand Date/Time Voltage B-C — See Template See Template
2033 Minimum Demand Voltage B-C D Volts/Scale 0 to 32,767
2034 to 2037 Minimum Demand Date/Time Voltage B-C — See Template See Template
2040 Last Demand Voltage C-A D Volts/Scale 0 to 32,767
2041 Present Demand Voltage C-A D Volts/Scale 0 to 32,767
2042 Running Average Demand Voltage C-A D Volts/Scale 0 to 32,767
2043 Maximum Demand Voltage C-A D Volts/Scale 0 to 32,767
2044 to 2047 Maximum Demand Date/Time Voltage C-A — See Template See Template
2048 Minimum Demand Voltage C-A D Volts/Scale 0 to 32,767
2049 to 2052 Minimum Demand Date/Time Voltage C-A — See Template See Template
2055 Last Demand Voltage L-L Average D Volts/Scale 0 to 32,767
2056 Present Demand Voltage L-L Average D Volts/Scale 0 to 32,767
2057 Running Average Demand Voltage L-L Average D Volts/Scale 0 to 32,767
2058 Maximum Demand Voltage L-L Average D Volts/Scale 0 to 32,767
2059 to 2062 Maximum Demand Date/Time Voltage L-L Average — See Template See Template
2063 Minimum Demand Voltage L-L Average D Volts/Scale 0 to 32,767
2064 to 2067 Minimum Demand Date/Time Voltage L-L Average — See Template See Template
2070 Last Demand Voltage A-N D Volts/Scale 0 to 32,767
2071 Present Demand Voltage A-N D Volts/Scale 0 to 32,767
2072 Running Average Demand Voltage A-N D Volts/Scale 0 to 32,767
2073 Maximum Demand Voltage A-N D Volts/Scale 0 to 32,767
2074 to 2077 Maximum Demand Date/Time Voltage A-N — See Template See Template
2078 Minimum Demand Voltage A-N D Volts/Scale 0 to 32,767
2079 to 2082 Minimum Demand Date/Time Voltage A-N — See Template See Template
2085 Last Demand Voltage B-N D Volts/Scale 0 to 32,767
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to0; -0.999 maps to 0.999;0.999 leadingmaps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
howtousethesetup-modecommands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
