Appendix B—Using the Command Interface 63230-300-212
Overview of the Command Interface April 2001
© 2001 Schneider Electric All Rights Reserved
184
3368 8001 None Resets turn-on time for all inputs.
3369 8001 None Resets all counters and timers for all I/Os.
3370 8001 Analog Output Number
Disables specified analog output.
3371 8001 Analog Output Number
Enables specified analog output.
3380 8001 9999 Disables all analog outputs.
3381 8002 9999 Enables all analog outputs.
Resets
4110 None None Resets min/max.
4210 8001 1 = Voltage
2 = Current
3=Both
Resets the register-based alarm logs.
5110 None None Resets all demand registers.
5111 None None Resets current demand.
5112 None None Resets voltage demand.
5113 None None Resets power demand.
5114 None None Resets input demand.
5115 None None Resets generic 1 demand for first group of 10 quantities.
5116 None None Resets generic 2 demand for second group of 10 quantities.
5210 None None Resets all min/max demand.
5211 None None Resets current min/max demand.
5212 None None Resets voltage min/max demand.
5213 None None Resets power min/max demand.
5214 None None Resets input min/max demand.
5215 None None Resets generic 1 min/max demand.
5216 None None Resets generic 2 min/max demand.
5910 8001 Bitmap Start new demand interval.
Bit0 = Power Demand
1 = Current Demand
2 = Voltage Demand
3 = Input Metering Demand
4 = Generic Demand Profile 1
5 = Generic Demand Profile 2
Table B– 2: Command Codes
Command
Code
Command Parameter
Register
Parameters Description
You must write to register 8001 the number that identifies which output you would like to use. To determine the identifying number, refer to
“I/O Point Numbers” on page 186 for instructions.
Data buffer location (register 8019) is the pointer to the first register where data will be stored. By default, return data begins at register 8020,
although you can use any of the registers from 8020–8149.
Take care when assigning pointers. Values may be corrupted if two commands
are using the same register.
