Appendix A—Abbreviated Register Listing 63230-300-212
Register Listing April 2001
© 2001 Schneider Electric All Rights Reserved
144
1693 Maximum Voltage, Negative Sequence, Angle — 0.1 0 to 3,599
1694 Maximum Voltage, Zero Sequence, Magnitude D Volts/Scale 0 to 32,767
1695 Maximum Voltage, Zero Sequence, Angle — 0.1 0 to 3,599
1696 Maximum Current, Sequence, Unbalance — 0.10% -1,000 to 1,000
1697 Maximum Voltage, Sequence, Unbalance — 0.10% -1,000 to 1,000
Accumulated Energy
1700 to 1703 Energy, Real In — WH 0 to 9,999,999,999,999,999
1704 to 1707 Energy, Reactive In — VArH 0 to 9,999,999,999,999,999
1708 to 1711 Energy, Real Out — WH 0 to 9,999,999,999,999,999
1712 to 1715 Energy, Reactive Out — VArH 0 to 9,999,999,999,999,999
1716 to 1719 Energy, Real Total (signed/absolute) — WH
-9,999,999,999,999,999 to
9,999,999,999,999,999
1720 to 1723 Energy, Reactive Total (signed/absolute) — VArH
-9,999,999,999,999,999-
9,999,999,999,999,999
1724 to 1727 Energy, Apparent — VAH 0 to 9,999,999,999,999,999
1728 to 1731 Energy, Conditional Real In — WH 0 to 9,999,999,999,999,999
1732 to 1735 Energy, Conditional Reactive In — VArH 0 to 9,999,999,999,999,999
1736 to 1739 Energy, Conditional Real Out — WH 0 to 9,999,999,999,999,999
1740 to 1743 Energy, Conditional Reactive Out — VArH 0 to 9,999,999,999,999,999
1744 to 1747 Energy, Conditional Apparent — VAH 0 to 9,999,999,999,999,999
1748 to 1750 Energy, Incremental Real In, Last Complete Interval — WH 0to999,999,999,999
1751 to 1753 Energy. Incremental Reactive In, Last Complete Interval — VArH 0to999,999,999,999
1754 to 1756 Energy, Incremental Real Out, Last Complete Interval — WH 0to999,999,999,999
1757 to 1759 Energy, Incremental Reactive Out, Last Complete Interval — VArH 0to999,999,999,999
1760 to 1762 Energy, Incremental Apparent, Last Complete Interval — VAH 0 to 999,999,999,999
1763 to 1766 Last Complete Interval Date/Time — See template See template
1767 to 1769 Energy, Incremental Real In, Present Interval — WH 0to999,999,999,999
1770 to 1772 Energy. Incremental Reactive In, Present Interval — VArH 0to999,999,999,999
1773 to 1775 Energy, Incremental Real Out, Present Interval — WH 0to999,999,999,999
1776 to 1778 Energy, Incremental Reactive Out, Present Interval — VArH 0to999,999,999,999
1779 to 1781 Energy, Incremental Apparent, Present Interval — VAH 0 to 999,999,999,999
1782 to 1784 Energy, Reactive, Quadrant 1 — VArH 0to999,999,999,999
1785 to 1787 Energy, Reactive, Quadrant 2 — VArH 0to999,999,999,999
1788 to 1790 Energy, Reactive, Quadrant 3 — VArH 0to999,999,999,999
1791 to 1793 Energy, Reactive, Quadrant 4 — VArH 0to999,999,999,999
1794 Conditional Energy Control Status ——
0=OFF
1=ON
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to0; -0.999 maps to 0.999;0.999 leadingmaps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
howtousethesetup-modecommands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
