Chapter 5—Input/Output Capabilities 63230-300-212
I/O Options April 2001
© 2001 Schneider Electric All Rights Reserved
70
The circuit monitor supports a variety of input and output options including:
• Digital Inputs
• Analog Inputs
• Mechanical Relay Outputs
• Solid State KYZ Pulse Outputs
• Analog Outputs
The circuit monitor has one KYZ output as standard. You can expand the I/O
capabilities by adding the optional I/O Extender (IOX) and the digital I/O
option card (IOC-44). Table 5–1 lists the many available I/O options. The I/O
options are explained in detail in the sections that follow.
Table 5–1: I/O Extender Options
I/O Extender Options Part Number
with no preinstalled I/Os, accepts up to 8 individual I/O
modules with a maximum of 4 analog I/Os
IOX
with 4 digital inputs (32 Vdc), 2 digital outputs (60 Vdc),
1analogoutput(4–20 mA), and 1 analog input (0–5Vdc)
IOX2411
with 4 digital inputs (120 Vac) and 4 analog inputs
(4–20 mA)
IOX0404
with 8 digital inputs (120 Vac) IOX08
Individual I/O Modules
Part Number
Digital I/Os
120 Vac input DI120AC
240 Vac input DI240AC
32 Vdc input (0.2ms turn on) polarized DI32DC
120 Vac output (3.5A maximum) DO120AC
200 Vdc output (3.5A maximum) DO200DC
240 Vac output (3.5A maximum) DO240AC
60 Vdc output (3.5A maximum) DO60DC
Analog I/Os
0 to 5 Vdc analog input AI05
4 to 20 mA analog input AI420
4to20mAanalogoutput AO420
The circuit monitor must be equipped with the I/O Extender (IOX) to install the
modules.
