Appendix A—Abbreviated Register Listing 63230-300-212
Register Listing April 2001
© 2001 Schneider Electric All Rights Reserved
138
1419 Minimum Current K-Factor, Phase B — 0.10 0 to 10,000
1420 Minimum Current K-Factor, Phase C — 0.10 0 to 10,000
1421 Minimum Crest Factor, Current, Phase A — 0.01 0 to 10,000
1422 Minimum Crest Factor, Current, Phase B — 0.01 0 to 10,000
1423 Minimum Crest Factor, Current, Phase C — 0.01 0 to 10,000
1424 Minimum Crest Factor, Current, Neutral — 0.01 0 to 10,000
1425 Minimum Crest Factor, Voltage A-N/A-B — 0.01 0 to 10,000
1426 Minimum Crest Factor, Voltage B-N/B-C — 0.01 0 to 10,000
1427 Minimum Crest Factor, Voltage C-N/C-A — 0.01 0 to 10,000
1430 Minimum Current Fundamental RMS Magnitude, Phase A A Amps/Scale 0 to 32,767
1431 Minimum Current Fundamental Coincident Angle, Phase A — 0.1 ° 0to3,599
1432 Minimum Current Fundamental RMS Magnitude, Phase B A Amps/Scale 0 to 32,767
1433 Minimum Current Fundamental Coincident Angle, Phase B — 0.1 ° 0to3,599
1434 Minimum Current Fundamental RMS Magnitude, Phase C A Amps/Scale 0 to 32,767
1435 Minimum Current Fundamental Coincident Angle, Phase C — 0.1 ° 0to3,599
1436 Minimum Current Fundamental RMS Magnitude, Neutral B Amps/Scale 0 to 32,767
1437 Minimum Current Fundamental Coincident Angle, Neutral — 0.1 ° 0to3,599
1438 Minimum Current Fundamental RMS Magnitude, Ground C Amps/Scale 0 to 32,767
1439 Minimum Current Fundamental Coincident Angle, Ground — 0.1 ° 0to3,599
1444 Minimum Voltage Fundamental RMS Magnitude, A-N/A-B D Volts/Scale 0 to 32,767
1445 Minimum Voltage Fundamental Coincident Angle, A-N/A-B — 0.1 ° 0to3,599
1446 Minimum Voltage Fundamental RMS Magnitude, B-N/B-C D Volts/Scale 0 to 32,767
1447 Minimum Voltage Fundamental Coincident Angle, B-N/B-C — 0.1 ° 0to3,599
1448 Minimum Voltage Fundamental RMS Magnitude, C-N/C-A D Volts/Scale 0 to 32,767
1449 Minimum Voltage Fundamental Coincident Angle, C-N/C-A — 0.1 ° 0to3,599
1450 Minimum Voltage Fundamental RMS Magnitude, N-G E Volts/Scale 0 to 32,767
1451 Minimum Voltage Fundamental Coincident Angle, N-G — 0.1 ° 0to3,599
1455 Minimum Fundamental Real Power, Phase A F kW/Scale -32,767 to 32,767
1456 Minimum Fundamental Real Power, Phase B F kW/Scale -32,767 to 32,767
1457 Minimum Fundamental Real Power, Phase C F kW/Scale -32,767 to 32,767
1458 Minimum Fundamental Real Power, Total F kW/Scale -32,767 to 32,767
1459 Minimum Fundamental Reactive Power, Phase A F kVAr/Scale -32,767 to 32,767
1460 Minimum Fundamental Reactive Power, Phase B F kVAr/Scale -32,767 to 32,767
1461 Minimum Fundamental Reactive Power, Phase C F kVAr/Scale -32,767 to 32,767
1462 Minimum Fundamental Reactive Power, Total F kVAr/Scale -32,767 to 32,767
1464 Minimum Distortion Power, Phase A F kW/Scale -32,767 to 32,767
1465 Minimum Distortion Power, Phase B F kW/Scale -32,767 to 32,767
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to0; -0.999 maps to 0.999;0.999 leadingmaps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
howtousethesetup-modecommands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
