Chapter 3—Operation 63230-300-212
Main Menu Overview April 2001
© 2001 Schneider Electric All Rights Reserved
12
The Main Menu on the display contains the menu options that you use to set
up and control the circuit monitor and its accessories and view metered data
andalarms.Figure3–4 on the left shows the options on the Main Menu. The
menus are briefly described below:
• Meters. This menu lets you view metered values that provide information
about power usage and power quality.
• Min/Max. This menu lets you view the minimum and maximum metered
values since the last reset of the min/max values with their associated
dates and times.
• View Alarms. This menu lets you view a list of all active alarms,
regardless of the priority. In addition, you can view a log of high priority
alarms, which contains the ten most recent high priority alarms.
• I/O Display. From this menu, you can view the designation and status of
each input or output. This menu will only display the I/Os present, so you
might not see all of the available menu items if you do not have a particular
I/O installed.
• Resets. This menu lets you reset energy, peak demand, and minimum/
maximum values.
• Setup. From this menu, you define the settings for the display such as
selecting the date format to be displayed. Creating custom quantities and
custom screens are also options on this menu. In addition, use this menu
to set up the circuit monitor parameters such as the CT and PT ratios. The
Setup menu is also where you define the communications, alarms, I/Os
and passwords.
• Diagnostics. From this menu, you can initiate the wiring error test. Also,
use this menu to read and write registers and view information about the
circuit monitor such as its firmware version and serial number.
MAIN MENU OVERVIEW
MAIN MENU
Meters
Min/Max
View Alarms
I/O Display
Resets
Setup
Diagnostics
METERS
Summary
Power
Power Quality
Energy
Power Demand
Current Demand
Custom
VIEW ALARMS
Active Alarms List
High Priority Log
I/O DISPLAY
Digital Inputs
Analog Inputs
Digital Outputs
Analog Outputs
RESETS
Energy
Demand
Min/Max
SETUP
Date & Time
Display
Communications
Meter
Alarm
I/O
Passwords
DIAGNOSTICS
Meter Information
CVM Information
Read/Write Regs
Wiring Error Test
MIN / MAX
Current
Voltage
Frequency
Power
Power Factor
THD
Figure 3–4: Menu options on the Main Menu
