Appendix A—Abbreviated Register Listing 63230-300-212
Register Listing April 2001
© 2001 Schneider Electric All Rights Reserved
152
2153
Predicted Demand Real Power, 3-Phase Total
Predicted real power demand at the end of the present interval
F kW/Scale -32,767 to 32,767
2154 Peak Demand Real Power, 3-Phase Total F kW/Scale -32,767 to 32,767
2155 to 2158 Peak Demand Date/Time Real Power, 3-Phase Total — See Template See Template
2159 to 2160 Cumulative Demand Real Power, 3-Phase Total F kW/Scale -2147483648 to 2147483647
2161 Power Factor, Average @ Peak Demand, Real Power — 0.001 1,000 -100 to 100
2162 Power Demand, Reactive @ Peak Demand, Real Power F kVAr/Scale -32,767 to 32,767
2163 Power Demand, Apparent @ Peak Demand, Real Power F kVA/Scale 0 to 32,767
2165 Last Demand Reactive Power, 3-Phase Total F kVAr /Scale -32,767 to 32,767
2166 Present Demand Reactive Power, 3-Phase Total F kVAr /Scale -32,767 to 32,767
2167 Running Average Demand Reactive Power, 3-Phase Total F kVAr /Scale -32,767 to 32,767
2168
Predicted Demand Reactive Power, 3-Phase Total
Predicted reactive power demand at the end of the present
interval
F kVAr /Scale -32,767 to 32,767
2169 Peak Demand Reactive Power, 3-Phase Total F kVAr /Scale -32,767 to 32,767
2170 to 2173 Peak Demand Date/Time Reactive Power, 3-Phase Total — See Template See Template
2174 to 2175 Cumulative Demand Reactive Power, 3-Phase Total F kVAr /Scale -2147483648 to 2147483647
2176 Power Factor, Average @ Peak Demand, Reactive Power — 0.001 1,000 -100 to 100
2177 Power Demand, Real @ Peak Demand, Reactive Power F kW/Scale -32,767 to 32,767
2178 Power Demand, Apparent @ Peak Demand, Reactive Power F kVA/Scale 0 to 32,767
2180 Last Demand Apparent Power 3-Phase Total F kVA /Scale -32,767 to 32,767
2181 Present Demand Apparent Power, 3-Phase Total F kVA /Scale -32,767 to 32,767
2182 Running Average Demand Apparent Power, 3-Phase Total F kVA /Scale -32,767 to 32,767
2183
Predicted Demand Apparent Power, 3-Phase Total
Predicted apparent power demand at the end of the present
interval
F kVA /Scale -32,767 to 32,767
2184 Peak Demand Apparent Power, 3-Phase Total F kVA /Scale -32,767 to 32,767
2185 to 2188 Peak Demand Date/Time Apparent Power, 3-Phase Total — See Template See Template
2189 to 2190 Cumulative Demand Apparent Power, 3-Phase Total F kVA /Scale -2147483648 to 2147483647
2191 Power Factor, Average @ Peak Demand, Apparent Power — 0.001 1,000 -100 to 100
2192 Power Demand, Real @ Peak Demand, Apparent Power F kW/Scale -32,767 to 32,767
2193 Power Demand, Reactive @ Peak Demand, Apparent Power F kVAr/Scale 0 to 32,767
2200
Unit Code, Input Channel #1
For software use only
——0to99
2201
Scale Code, Input Channel #1 ——-3 to 3, Default = 0
2202 Last Demand, Input Channel #1 ——0 to 32,767, Default = 0
2203 Present Demand, Input Channel #1 ——0to32,767
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to0; -0.999 maps to 0.999;0.999 leadingmaps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
howtousethesetup-modecommands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
