63230-300-212 Chapter 3—Operation
April 2001 Resetting Min/Max, Demand, and Energy Values
37
© 2001 Schneider Electric All Rights Reserved
A reset clears the circuit monitor’s memory of the last recorded value. For
example, you might need to reset monthly peak demand power. From the
Reset menu, shown in Figure 3–6, you can reset the following values:
• Energy—accumulated energy and conditional energy
• Demand—peak power demand and peak current demand
• Min/Max—minimum and maximum values for all real-time readings
Figure 3–6: Performing resets from the Reset menu
A password is required to reset any of the options on the Reset menu. The
default password is 0. See “Setting Up Passwords” on page 27 for more
information about passwords.
You can perform resets from the circuit monitor as described in this section
or if you are using
SMS, you can set up a task to perform the reset
automatically at a specified time. See the
SMS online help for instructions.
NOTE: To stop users from using the display to reset energy, peak demand,
and min/max values, see “Advanced Meter Setup” on page 34 for instructions
on using the reset locking feature.
To perform resets, follow these steps:
1. From the Main Menu, select Resets.
The Resets menu displays.
2. Use the arrow buttons to scroll through the menu options on the
Resets menu. To select a menu option, press the enter button.
Depending on the option you selected, the screen for that value displays.
RESETTING MIN/MAX, DEMAND,
AND ENERGY VALUES
MAIN MENU
Meters
Min/Max
View Alarms
I/O Display
Resets
Setup
Diagnostics
RESETS
Energy
Demand
Min/Max
RESETS
Energy
Demand
Min/Max
RESET ENERGY
Accumulated No
RESET DEMAND
PK Power Demand No
PK Amp Demand No
RESET MIN/MAX
Min/Max No
