63230-300-212 Chapter 3—Operation
April 2001 Viewing I/O Status
43
© 2001 Schneider Electric All Rights Reserved
TheI/ODisplaymenushowstheON or OFF status of the digital inputs or
outputs. For analog inputs and outputs, it displays the present value. To view
the status of inputs and outputs:
1. From the Main Menu, select I/O Display.
The I/O Display screen displays.
2. Select the input or output on which you’d like to view the status. In this
example, we selected Digital Outputs to display the status of the
KYZ
output.
3. Press the menu button to exit.
VIEWING I/O STATUS
I/O DISPLAY
Digital Inputs
Analog Inputs
Digital Outputs
Analog Outputs
DIGITAL OUTPUTS
KYZ OFF
