63230-300-212 Chapter 3—Operation
April 2001 Chapter Contents
9
© 2001 Schneider Electric All Rights Reserved
This chapter tells how to set up the circuit monitor from the display only.
Some advanced features, such as configuring the onboard logs of the circuit
monitor, must be set up over the communications link using
SMS. Refer to the
SMS instruction bulletin and online help file for instructions on setting up
advanced features not accessible from the display.
CHAPTERCONTENTS .......................................9
OPERATINGTHEDISPLAY ..................................10
HowtheButtonsWork ....................................10
DisplayMenuConventions ................................11
SelectingaMenuOption ..............................11
Changing a Value ....................................11
MAINMENUOVERVIEW .....................................12
CONFIGURING THE CIRCUIT MONITOR USING THE SETUP MENU . 13
SettingUptheDisplay ....................................13
SettingUptheCommunications ............................14
SettingtheDeviceAddress ............................14
RS-485, RS-232, and Infrared Port Communications Setup . . . 15
EthernetCommunicationsCard(ECC)Setup ..............16
SettingUptheMeteringFunctionsoftheCircuitMonitor .........16
SettingUpAlarms .......................................18
CreatingaNewCustomAlarm ..........................19
SettingUpandEditingAlarms ..........................21
SettingUpI/Os .........................................23
Selecting I/O Modules . ...............................23
ConfiguringI/OModules...............................25
SettingUpPasswords ....................................27
AdvancedSetupFeatures .................................28
CreatingCustomQuantitiestobeDisplayed ...............28
CreatingCustomScreens .............................31
Viewing Custom Screens ..............................34
AdvancedMeterSetup................................34
RESETTINGMIN/MAX,DEMAND,ANDENERGYVALUES .........37
VIEWINGMETEREDDATA ...................................38
ViewingMeteredDatafromtheMetersMenu ..................38
Viewing Minimum and Maximum Values from the Min/Max Menu . . 39
VIEWINGALARMS..........................................41
ViewingActiveAlarms ....................................42
View and Acknowledging High Priority Alarms . . . ..............42
VIEWINGI/OSTATUS .......................................43
READINGANDWRITINGREGISTERS..........................44
PERFORMINGAWIRINGERRORTEST ........................45
Running the Diagnostics Wiring Error Test . ...................46
CHAPTER 3—OPERATION
CHAPTER CONTENTS
