63230-300-212 Appendix A—Abbreviated Register Listing
April 2001 Register Listing
167
© 2001 Schneider Electric All Rights Reserved
4016
Time Sync Signal
Health Status
—
0x0000 to
0xFFFF
Bitmap of Time Sync Signal Health Status:
0 = OK, 1 = Error
Bit 00 = Summary Bit , time sync signal fatal error
Bit 01 = Lost time sync signal
Bit 02 = Summary Bit , invalid data
Bit 12 = Good time sync signal received
Bit 13 = Reserve antenna in use
Bit 14 = DST warning
Bit15=DSTineffect
4017
GPS Time Sync
Accuracy
milli-
seconds
0to1,000 GPSTimeSyncAccuracy
4021
Present Module Type
Option Slot A
— 0to7
Indicates the type of Option Module present in Option Slot A.
0=NotInstalled
1=IOC44
6 = Ethernet Option Module
4022
Present Module Type
Option Slot B
— 0to7
Indicates the type of Option Module present in Option Slot B.
0=NotInstalled
1=IOC44
6 = Ethernet Option Module
4023
Present Module Type
Pluggable IO
— 0, 5
Indicates the presence of the pluggable IO rack.
0 = No module present
5 = Pluggable IO rack present
4200–4299
Digital Output/Alarm
Ta bl e
— 0 to 17081
Table of digital output/alarm associations. Upper byte is IO Point
Number (1 to 66). Lower byte is Alarm Index Number (1 to 185).
4300–4329
IO Point Number 1
Standard Digital
Output (KYZ)
Refer to digital Output template below.
4360–4389
IO Point Number 3
(A01)
Register contents depend on IO Point Type. Refer to templates
below.
4390–4419
IO Point Number 4
(A02)
Register contents depend on IO Point Type. Refer to templates
below.
4420–4449
IO Point Number 5
(A03)
Register contents depend on IO Point Type. Refer to templates
below.
4450–4479
IO Point Number 6
(A04)
Register contents depend on IO Point Type. Refer to templates
below.
4480–4509
IO Point Number 7
(A05)
Register contents depend on IO Point Type. Refer to templates
below.
4510–4539
IO Point Number 8
(A06)
Register contents depend on IO Point Type. Refer to templates
below.
4540–4569
IO Point Number 9
(A07)
Register contents depend on IO Point Type. Refer to templates
below.
4570–4599
IO Point Number 10
(A08)
Register contents depend on IO Point Type. Refer to templates
below.
4840–4869
IO Point Number 19
(B01)
Register contents depend on IO Point Type. Refer to templates
below.
4870–4899
IO Point Number 20
(B02)
Register contents depend on IO Point Type. Refer to templates
below.
4900–4929
IO Point Number 21
(B03)
Register contents depend on IO Point Type. Refer to templates
below.
Table A–4:Abbreviated Register List for I/O Status
Register
Number
Name Units Range Description
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions
on how to use the setup-mode commands.
