63230-300-212 Chapter 3—Operation
April 2001 Performing a Wiring Check
47
© 2001 Schneider Electric All Rights Reserved
2. Select Wiring Error Test from the menu.
The circuit monitor asks if the wiring matches the test assumptions.
3. Press the down arrow button.
The circuit monitor asks if the expected displacement power factor is
between 0.60 lagging and 0.99 leading.
4. Press the down arrow button, again.
The circuit monitor asks if you’dliketoperformawiringcheck.
5. Select “Yes ” to perform the test by pressing the up arrow button and then
pressing the enter button.
The circuit monitor performs the wiring test.
If it doesn’t find any errors, the circuit monitor displays “Wire test
complete. No errors found!”. If it finds possible errors, it displays “Error
detected. See following screens for details.”
6. Press the arrow buttons to scroll through the wiring error messages.
Table 3–12 on page 48 explains the possible wiring error messages.
7. Turn off all power supplying the circuit monitor. Verify that the power is off
using a properly rated voltage testing device.
Test Assumptions:
Va and Vn for 4wire
Va and Vb for 3wire
are correct.
Test Assumptions:
Displacement PF is
between 0.60 lag
and 0.99 lead.
Perform Test No
