63230-300-212 Appendix A—Abbreviated Register Listing
April 2001 Register Listing
141
© 2001 Schneider Electric All Rights Reserved
1560 Maximum True Power Factor, Phase A — 0.001 1,000 -100 to 100
1561 Maximum True Power Factor, Phase B — 0.001 1,000 -100 to 100
1562 Maximum True Power Factor, Phase C — 0.001 1,000 -100 to 100
1563 Maximum True Power Factor, Total — 0.001 1,000 -100 to 100
1564 Maximum Alternate True Power Factor, Phase A — 0.001 0 to 2,000
1565 Maximum Alternate True Power Factor, Phase B — 0.001 0 to 2,000
1566 Maximum Alternate True Power Factor, Phase C — 0.001 0 to 2,000
1567 Maximum Alternate True Power Factor, Total 0.001 0 to 2,000
1568 Maximum Displacement Power Factor, Phase A — 0.001 1,000 -100 to 100
1569 Maximum Displacement Power Factor, Phase B — 0.001 1,000 -100 to 100
1570 Maximum Displacement Power Factor, Phase C — 0.001 1,000 -100 to 100
1571 Maximum Displacement Power Factor, Total — 0.001 1,000 -100 to 100
1572 Maximum Alternate Displacement Power Factor, Phase A — 0.001 0 to 2,000
1573 Maximum Alternate Displacement Power Factor, Phase B — 0.001 0 to 2,000
1574 Maximum Alternate Displacement Power Factor, Phase C 0.001 0 to 2,000
1575 Maximum Alternate Displacement Power Factor, Total — 0.001 0 to 2,000
1580 Maximum Frequency —
0.01 Hertz
0.1 Hertz
(50/60) 2,300 to 6,700 (400)
3,500to4,500
1581 Maximum Temperature — 0.1 °C -1,000 to 1,000
1590 Maximum Auxiliary Analog Input Value, User-Selected Input 1 —
Refer to Analog Input
Setup
-32,767 to 32,767
1591 Maximum Auxiliary Analog Input Value, User-Selected Input 2 —
Refer to Analog Input
Setup
-32,767 to 32,767
1592 Maximum Auxiliary Analog Input Value, User-Selected Input 3 —
Refer to Analog Input
Setup
-32,767 to 32,767
1593 Maximum Auxiliary Analog Input Value, User-Selected Input 4 —
Refer to Analog Input
Setup
-32,767 to 32,767
1594 Maximum Auxiliary Analog Input Value, User-Selected Input 5 —
Refer to Analog Input
Setup
-32,767 to 32,767
1595 Maximum Auxiliary Analog Input Value, User-Selected Input 6 —
Refer to Analog Input
Setup
-32,767 to 32,767
1596 Maximum Auxiliary Analog Input Value, User-Selected Input 7 —
Refer to Analog Input
Setup
-32,767 to 32,767
1597 Maximum Auxiliary Analog Input Value, User-Selected Input 8 —
Refer to Analog Input
Setup
-32,767 to 32,767
1598 Maximum Auxiliary Analog Input Value, User-Selected Input 9 —
Refer to Analog Input
Setup
-32,767 to 32,767
1599
Maximum Auxiliary Analog Input Value, User-Selected Input
10
—
Refer to Analog Input
Setup
-32,767 to 32,767
1600 Maximum THD/thd Current, Phase A — 0.10% 0 to 32,767
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to 0; -0.999 maps to 0.999;0.999 leading maps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
how to use the setup-mode commands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
