63230-300-212 Appendix A—Abbreviated Register Listing
April 2001 Register Listing
173
© 2001 Schneider Electric All Rights Reserved
Table A–5:Registers for Alarm Position Counters
Register
Number
Description
Scale
Factor
Units Register Range
10000 to
10009
P1 Alarm Queue
Queue of last ten active priority 1 alarms
—— 1to185
10010
P1 Acknowledge Status
Acknowledge status for each of the P1 alarms in the queue
— Bitmap 0x0000 to 0x03FF
10011 to
10022
Active Alarm Map
Each bit corresponds to an Alarm Type:
Bit00 = Alarm #01
Bit01 = Alarm #02 ... etc.
— Bitmap 0x0000 to 0xFFFF
10023
Active Alarm Status
Active Alarms:
Bit00 = 1 if any priority 1-3 alarm is active
Bit01 = 1 if a "High" (1) priority alarm is active
Bit02 = 1 if a "Medium" (2) priority alarm is active
Bit03 = 1 if a "Low" (3) priority alarm is active
Remaining bits not used.
— Bitmap 0x0000 to 0x000F
10024
Latched Active Alarm Status
Latched Active Alarms: (from the last time the register was
cleared)
Bit00 = 1 if any priority 1-3 alarm is active
Bit01 = 1 if a "High" (1) priority alarm is active
Bit02 = 1 if a "Medium" (2) priority alarm is active
Bit03 = 1 if a "Low" (3) priority alarm is active
Remaining bits not used.
— Bitmap 0x0000 to 0x000F
10025
Total Counter
Total alarm counter, including all priorities 1, 2 and 3
— 1.0 0 to 32,767
10026
P3 Counter
Low alarm counter, all priority 3s
— 1.0 0 to 32,767
10027
P2 Counter
Medium alarm counter, all priority 2s
— 1.0 0 to 32,767
10028
P1 Counter
High alarm counter, all priority 1s
— 1.0 0 to 32,767
10029 to
10040
Pickup Mode Selection
Selection of absolute or relative pickup test for each of the
Alarm Types (if applicable, based on type)
0 = Absolute (default), 1 = Relative
Bit00 = Alarm #01
Bit01 = Alarm #02 ... etc.
— Bitmap 0x0 to 0xFFFF
10115 Alarm Type #001 Counter — 1.0 0 to 32,767
10116 Alarm Type #002 Counter — 1.0 0 to 32,767
10117 Alarm Type #003 Counter — 1.0 0 to 32,767
10118 Alarm Type #004 Counter — 1.0 0 to 32,767
10119 Alarm Type #005 Counter — 1.0 0 to 32,767
10120 Alarm Type #006 Counter — 1.0 0 to 32,767
10121 Alarm Type #007 Counter — 1.0 0 to 32,767
10122 Alarm Type #008 Counter — 1.0 0 to 32,767
10123 Alarm Type #009 Counter — 1.0 0 to 32,767
10124 Alarm Type #010 Counter — 1.0 0 to 32,767
10125 Alarm Type #011 Counter — 1.0 0 to 32,767
10126 Alarm Type #012 Counter — 1.0 0 to 32,767
10127 Alarm Type #013Counter — 1.0 0 to 32,767
10128 Alarm Type #014 Counter — 1.0 0 to 32,767
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
how to use the setup to mode commands.
