Appendix A—Abbreviated Register Listing 63230-300-212
Register Listing April 2001
© 2001 Schneider Electric All Rights Reserved
130
REGISTER LISTING
Table A–3:Abbreviated Register List
Register
Number
Description
Scale
Factor
Units Register Range
100msReal-TimeReadings
1000 Current, Phase A A Amps/Scale 0 to 32,767
1001 Current, Phase B A Amps/Scale 0 to 32,767
1002 Current, Phase C A Amps/Scale 0 to 32,767
1003 Current, Neutral B Amps/Scale 0 to 32,767
1004 Current, Ground C Amps/Scale 0 to 32,767
1005 Current, 3-Phase Average A Amps/Scale 0 to 32,767
1006 Current, Apparent RMS A Amps/Scale 0 to 32,767
1020 Voltage, A-B D Volts/Scale 0 to 32,767
1021 Voltage, B-C D Volts/Scale 0 to 32,767
1022 Voltage, C-A D Volts/Scale 0 to 32,767
1023 Voltage, L-L Average D Volts/Scale 0 to 32,767
1024 Voltage, A-N D Volts/Scale 0 to 32,767
1025 Voltage, B-N D Volts/Scale 0 to 32,767
1026 Voltage, C-N D Volts/Scale 0 to 32,767
1027 Voltage, N-G E Volts/Scale 0 to 32,767
1028 Voltage, L-N Average D Volts/Scale 0 to 32,767
1040 Real Power, Phase A F kW/Scale -32,767 to 32,767
1041 Real Power, Phase B F kW/Scale -32,767 to 32,767
1042 Real Power, Phase C F kW/Scale -32,767 to 32,767
1043 Real Power, Total F kW/Scale -32,767 to 32,767
1044 Reactive Power, Phase A F kVAr/Scale -32,767 to 32,767
1045 Reactive Power, Phase B F kVAr/Scale -32,767 to 32,767
1046 Reactive Power, Phase C F kVAr/Scale -32,767 to 32,767
1047 Reactive Power, Total F kVAr/Scale -32,767 to 32,767
1048 Apparent Power, Phase A F kVA/Scale -32,767 to 32,767
1049 Apparent Power, Phase B F kVA/Scale -32,767 to 32,767
1050 Apparent Power, Phase C F kVA/Scale -32,767 to 32,767
1051 Apparent Power, Total F kVA/Scale -32,767 to 32,767
1060 True Power Factor, Phase A — 0.001 -100 to 1,000 to 100
1061 True Power Factor, Phase B — 0.001 -100 to 1,000 to 100
1062 True Power Factor, Phase C — 0.001 -100 to 1,000 to 100
1063 True Power Factor, Total — 0.001 -100 to 1,000 to 100
1064 Alternate True Power Factor, Phase A — 0.001 0 to 2,000
See “How Power Factor is Stored in the Register” on page 128.
The alternate storage method for power factor (PF) is useful for outputting PF on analog outputs. The PF value is stored as a positive value
between 0 and 2, centered around 1 (unity). A value of 0 lagging maps to0; -0.999 maps to 0.999;0.999 leadingmaps to 1.001; and 0 leading
maps to 2. The alternate PF is also stored with a scale factor 0.001.
These configuration registers require that you enter the setup mode to change the register’s contents. Issue command 9020 to enter setup
mode and 9021 to exit setup mode. See “Using the Command Interface to Change Configuration Registers” on page 187 for instructions on
howtousethesetup-modecommands.
Quantity available for 4-wire system only. Value set to -32,768 if not available.
